Dell PowerEdge R740xd Server

  • From: $566
  • 100% Dell Original Components
  • 30-Day Money-Back Guarantee
  • Dell Certified Technicians & Engineers
100% Satisfaction Guarantee - The xByte Difference
Dell Platinum Partner Dell Outlet Platinum
Image of Dell PowerEdge R740xd Server
  • Dell Server Generation:14th
  • Server Model:R740xd
  • Server Type:Rack
  • CPU:Up to 2 x Intel Xeon SP Multi Core
  • Memory:24 DIMM Slots (Max 3TB)
  • RAID:PERC H330, PERC H730P 2GB NV, PERC H740P 8GB NV, PERC H750
  • HDD:2.5" or 3.5" Hot Swap SAS, SATA and Near Line SAS, NVMe SSD
  • Power Supply:495W or 750W, 1100W, 1600W, 2000W and 2400W Hot Swap Redundant
  • Riser:Up to 8 PCIe Slots (Gen 3 slots, max 4 x 16 bandwidth)
  • Rack Units:2U
SKU: >R740XD

Videos

Resources

Blogs

Tech Specs

  • Base:
    PowerEdge R740xd Server
  • Processor:
    Up to two 2nd Generation Intel® Xeon® SP, up to 28 cores per processor
  • Memory:
    24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB max
    Up to 12 NVDIMM, 192 GB Max
    Supports registered ECC DDR4 DIMMs only
  • Storage Controllers:
    Internal controllers: PERC H730p, H740p, HBA330, Software RAID (SWRAID) S140
    External PERC (RAID): H840
    External HBAs (non-RAID): 12 Gbps SAS HBA
    Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB or 240 GB
  • Drive Bays:
    Front bays: Up to 24 x 2.5 SAS/SATA (HDD/SSD), NVMe SSD max 153TB or up to 12 x 3.5” SAS/SATA HDD max 120TB
    Mid bay: Up to 4 x 2.5”, max 25TB SAS/SATA (HDD/SSD), NVMe SSD max 25TB or up to 4 x 3.5”, max 40TB
    Rear bays: Up to 4 x 2.5”, max 25TB SAS/SATA (HDD/SSD), NVMe SSD or up to 2 x 3.5” max 20TB SAS/SATA HDD
  • Power Supplies:
    Titanium 750W, Platinum
    Titanium 750W, Platinum
    495W, 750W, 1100W, 1600W, and 2000W
    48VDC 1100W, 380HVDC 1100W, 240HVDC 750W
    Hot plug power supplies with full redundancy
    Up to 6 hot plugs fans with full redundancy
  • Dimensions:
    Form Factor: 2U Rack Server
    Max Depth: 715.5 mm
  • Embedded Management:
    IPMI 2.0 compliant
    iDRAC9 with Lifecycle Controller (Express, Enterprise)
    Quick Sync 2 wireless module optional
  • Bezel:
    Optional LCD or security bezel
  • OpenManage™ Software:
    OpenManage Enterprise
    OpenManage Essentials
    OpenManage Mobile
    OpenManage Power Center
  • Integrations:
    Microsoft® System Center, VMware® vCenter™, BMC Software
  • Connections:
    Nagios & Nagios XI, Oracle Enterprise Manager, HP Operations Manager, IBM Tivoli Netcool/OMNIbus, IBM Tivoli® Network Manager, CA Network and Systems Management
  • Security:
    TPM 1.2/2.0, TCM 2.0 optional
    Cryptographically signed firmware
    Secure Boot
    System Lockdown
    System Erase
  • I/O & Ports:
    Network daughter card options
    4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE
    Front ports: VGA, 2 x USB 2.0, dedicated IDRAC Direct Micro-USB
    Rear ports: VGA, Serial, 2 x USB 3.0, dedicated iDRAC network port
    Video card: VGA
    Riser options with p to 8 PCIe Gen 3 slots,
    maximum of 4 x 16 slots
  • GPU Options:
    GPU options available only on 24 x 2.5” drive chassis
    Nvidia Tesla P100, K80, K40, Grid M60, M10, P4, Quadro P4000. AMD S7150, S7150X2
  • Supported Operating Systems:
    BIOS
    Citrix XenServer 7.1
    Red Hat Enterprise Linux 9
    Red Hat® Enterprise Linux 6
    Red Hat® Enterprise Linux 7
    Red Hat® Enterprise Linux 8
    SUSE Linux ES 12
    SuSE Linux ES 15
    Ubuntu Server 16.04 LTS
    Ubuntu Server 20.04 LTS
    Ubuntu Server 22.04 LTS
    Ubuntu® Server 18.04 LTS
    VMware ESXi 6.0
    VMware ESXi 6.5
    VMware ESXi 6.7
    VMware ESXi 7.0
    VMware ESXi 8.0
    Windows Server 2012 R2
    Windows Server 2016
    Windows Server 2019 LTSC
    Windows Server 2022 LTSC
