What is Dell VxRail?

Dell EMC VxRail delivers more highly differentiated features and benefits based on proprietary VxRail HCI System Software. This unique combination automates
deployment, provides full stack lifecycle management and facilitates critical upstream and downstream integration points that create a truly seamless experience.

Software defined architecture

consolidates compute, storage, virtualization, and management

Full stack integration with

VMware technologies, including

VMware Cloud Foundation

Smart Fabric Services for VxRail

automates network setup, simplifying

and accelerating deployment

Provides a single point of

support by default for all

software and hardware

Dell EMC VxRail is powered by PowerEdge server platforms and is the only jointly engineered HCI solution with VMware,
optimized for VMware vSAN, and designed to enable deep integration across the VMware ecosystem.

E Series

Low profile, cost-effective, go “everywhere” platform. 1U platform with an all NVMe option and NVIDIA GPUs. Single or dual socket options powered by Intel Xeon or AMD EPYC processors. Ideal for remote, branch office, or edge locations where space is at a premium. Uses include high performance computing, VDI, AI/ML, and in-memory databases.

E660 w/ PowerEdge R650

CHASSIS: 10 x 2.5" Drive Bays

PROFILES: All-flash/NVMe/Hybrid

CPU(s): Single/Dual Intel Scalable Gen 3

RAM: Up to 4096GB

STORAGE CAP: Up to 123TB

NETWORK: Up to 3x, Dual/Quad 100GbE

E665 w/ PowerEdge R6515

CHASSIS: Up to 10 x 2.5" Drive Bays

PROFILES: All-flash/NVMe/Hybrid

CPU(s): Single 2nd/3rd Gen AMD EPYC

RAM: Up to 1024GB

STORAGE CAP: Up to 123TB

NETWORK: Single, Up to 25GbE Dual

P Series

Performance-intensive 2U platform configurable with single, dual or quad Intel Xeon Scalable processors, or a single AMD EPYC processor with up to 64 cores. Ideal for

business-critical workloads requiring high performance. Use cases include in-memory intensive database applications such as SAP HANA, HPC and AI/ML.

P670 w/ PowerEdge R750

CHASSIS: Up to 28 x 2.5" Drive Bays

PROFILES: All-flash/NVMe

CPU(s): Single/Dual Intel Scalable Gen 3

RAM: Up to 4096GB

STORAGE CAP: Up to 322TB

NETWORK: Up to 3x, Dual/Quad 100GbE

P580N w/ PowerEdge R840

CHASSIS: 24 x 2.5" Drive Bays

PROFILES: NVMe

CPU(s): Quad Intel Scalable Gen 2

RAM: Up to 6144GB

STORAGE CAP: Up to 306TB

NETWORK: Up to 3x, Dual/Quad 100GbE

P675 w/ PowerEdge R7515

CHASSIS: 24 x 2.5" Drive Bays

PROFILES: All-flash/NVMe

CPU(s): Single 2nd/3rd Gen AMD EPYC

RAM: Up to 2048GB

STORAGE CAP: Up to 307TB

NETWORK: Up to 3x, Dual/Quad 100GbE

V Series

Virtualization-extended 2U platform with GPU hardware for graphics-intensive desktops and graphicscompute workloads.


V670 w/ PowerEdge R750

CHASSIS: 24 x 2.5" Drive Bays

PROFILES: All-flash

CPU(s): Dual Intel Scalable Gen 3

RAM: Up to 4096GB

STORAGE CAP: 161TB

NETWORK: Up to 3x, Dual/Quad 100GbE

D Series

Designed to withstand extreme conditions

such as intense heat and cold, shock,

vibration, dust, humidity and EMI.


D560 w/ PowerEdge XR2

CHASSIS: 8 x 2.5" Drive Bays

PROFILES: All-flash/Hybrid

CPU(s): Single/Dual Intel Scalable Gen 2

RAM: Up to 1024GB

STORAGE CAP: Up to 46TB

NETWORK: Single, Dual up to 25GbE

S Series

Storage-dense 2U platform available as single or dual-socket with hybrid storage options to deliver a maximum capacity of 144 TB per node.


S670 w/ PowerEdge R750

CHASSIS: 12 x 3.5” front, plus 4 x 2.5” rear

PROFILES: Hybrid

CPU(s): Single/Dual Intel Scalable Gen 3

RAM: Up to 4096GB

STORAGE CAP: Up to 144TB

NETWORK: Up to 3x, Dual/Quad 100GbE

G Series

Compute-dense 2U/4-node platform available as single or dual-socket with up to 224 cores. Ideal for environments requiring max processing.


G560 w/ PowerEdge C6400

CHASSIS: Up to 4x C6420s w/ 6 x 2.5” drives

PROFILES: All-flash/Hybrid

CPU(s): Single/Dual Intel Scalable Gen 2

RAM: Up to 2048GB

STORAGE CAP: Up to 38TB

NETWORK: Up to 3x, Dual/Quad 100GbE

Why Dell VxRail?

Accomplishments, endorsements and distinctions that demonstrate the Dell Technologies commitment to helping you innovate, grow and develop your business.

51%

Lower five-year cost of operations

92%

Less unplanned downtime

452%

five-year return on investment

Who uses Dell VxRail?

VxRail provides a simple, cost effective hyperconverged solution that solves a wide range of your challenges and supports almost any use case, including tier-one applications and mixed workloads. VxRail enables faster, better, and simpler delivery of virtual desktops, business-critical applications, and remote office infrastructure.
