Dell PowerEdge T550 Server

Tech Specs

• Base:
  PowerEdge T550 Server
• Form Factor:
  5U Tower Server
• Processor:
  Up to two 3rd Generation Intel Xeon Scalable processors with up to 36 cores per processor
• Dimensions:
  Height – 459.0 mm (18.07 inches)
  Width – 200 mm (7.87 inches)
  Depth (without bezel) – 663.5 mm (26.12 inches)
  Depth (with bezel) – 680.5 mm (26.79 inches)
• Power Supplies:
  600 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap
  700 W Titanium Mixed Mode (200-240Vac or 240Vdc) hot swap
  800 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap
  1100 W -48Vdc hot swap(CAUTION: only works with -48Vdc to -60Vdc power input)
  1100 W Titanium Mixed Mode (100-240Vac or 240Vdc) hot swap
  1400 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap
  1800 W Titanium Mixed Mode (200-240Vac or 240Vdc) hot swap
  2400 W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap
• Memory:
  16 DDR4 DIMM slots, supports RDIMM 2 TB max, speeds up to 3200 MT/s
  Supports registered ECC DDR4 DIMMs only
• Drive Bays:
  Front Bays:
  Up to 8 x 2.5-inch SAS/SATA (HDD) max 120 TB
  Up to 16 x 2.5-inch SAS/SATA (HDD) max 240 TB
  Up to 24 x 2.5-inch SAS/SATA (HDD) max 360 TB
  Up to 8 x 3.5-inch SAS/SATA (HDD/SAS) max 120 TB
  Up to 8 x 3.5-inch SAS/SATA (HDD) + 8 x 2.5-inch NVMe (SSD) max 240 TB
• Fans:
  Standard (STD) fans/High performance (HPR) silver fans
  Up to eight hot swap fans
• Cooling Options:
  Air cooling
• Bezel:
  Optional LCD or Security Bezel
• Embedded Management:
  iDRAC9
  iDRAC Service Module
  iDRAC Direct
  iDRAC RESTful with Redfish
  Quick Sync 2 wireless module
• OpenManage™ Software:
  OpenManage Enterprise
  OpenManage Power Manager plugin
  OpenManage SupportAssist plugin
  OpenManage Update Manager plugin
• Mobility:
  OpenManage Mobile
• Integrations and Connections:
  OpenManage Integrations:
  BMC Truesight
  Microsoft® System Center
  Red Hat® Ansible® Modules
  VMware vCenter and vRealize Operations Manager

  OpenManage Connections:
  IBM Tivoli® Netcool/OMNIbus
  IBM Tivoli® Network Manager IP Edition
  Micro Focus® Operations Manager I
  Nagios® Core
  Nagios® XI
• Security:
  Cryptographically signed firmware
  Secure Boot
  Secure Erase
  Silicon Root of Trust
  System Lockdown (requires iDRAC9 Enterprise or Datacenter)
  TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
• Embedded NIC:
  2 x 1 GbE LOM
• Network Options:
  1 x OCP 3.0
• GPU Options:
  Up to two double wide 300 W NVIDIA A40, or five single wide 70 W NVIDIA T4 accelerators
• Ports:
  Front Ports:
  1 x USB 2.0
  1 x USB 3.0
  1 x iDRAC Direct (Micro-AB USB) port

  Rear Ports:
  1 x USB 2.0
  1 x iDRAC Direct (Micro-AB USB) port
  1 x Serial (optional)
  1 x USB 3.0
  2 x Ethernet
  1 x VGA

  Internal:
  1 x USB 3.0 (optional)
• PCIe:
  Up to 6 x PCIe Gen4 slots
• Operating Systems and Hypervisors:
  Canonical® Ubuntu® Server LTS
  Microsoft® Windows Server® with Hyper-V
  Red Hat® Enterprise Linux
  SUSE® Linux Enterprise Server
  Citrix Hypervisor
  VMware ESXi
• Storage Controllers:
  Internal controllers: HBA345, PERC H345, PERC H355, PERC H745, PERC H755, S150, H755N, HBA355i
  Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs, USB
  External PERC (RAID): PERC H840
  External HBAs (non-RAID): HBA355e
