Dell PowerEdge R6525 Server

  • From: $3,843
  • 100% Dell Original Components
  • 30-Day Money-Back Guarantee
  • Dell Certified Technicians & Engineers
100% Satisfaction Guarantee - The xByte Difference
Dell Platinum Partner Dell Outlet Platinum
Image of Dell PowerEdge R6525 Server
  • Dell Server Generation:15th
  • Server Model:R6525
  • Server Type:Rack
  • CPU:Two 2nd or 3rd Gen AMD EPYC Processors with up to 64 cores per processor
  • Memory:32 DIMM Slots (Max 4TB)
  • RAID:PERC 10.5, HBA345, H345, H745, H840, 12G SAS HBA or PERC11 H755, H755N
  • HDD:2.5" or 3.5" Hot Swap NVMe, SAS, SATA and Near Line SAS
  • Power Supply:800W, 1100W, and 1400W Hot Swap Redundant
  • Riser:3 x Gen4 slots (x16) at 16GT/s
  • Rack Units:1U
SKU: >R6525

Videos

Resources

Tech Specs

  • Base:
    PowerEdge R6525 Server
  • Form Factor:
    1U Rack Server
  • Processor:
    Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor
  • Availability:
    Hot plug redundant Hard drives, Fans, PSUs
  • Power Supplies:
    800W Platinum
    1400W Platinum
    1100W Titanium
  • Fans:
    Hot plug Fans
  • Memory:
    Up to 32 x DDR4
    Maximum RAM
    RDIMM 2 TB
    LRDIMM 4TB Max
    Bandwidth up to 3200 MT/S
  • Controllers:
    PERC 10.5 – HBA345, H345, H745, H840, 12G SAS HBA
    PERC 11 – H755, H755N
    Chipset SATA/SW RAID (S150): Yes
  • Drive Bays:
    Front Bays:
    Up to 4 x 3.5” hot plug SAS/SATA (HDD)
    Up to 8 x 2.5” hot plug SAS/SATA (HDD)
    Up to 12 x 2.5” (10 Front + 2 Rear) hot plug SAS/SATA/NVMe

    Optional Internal Bays:
    2 x M.2 (BOSS) Optional Rear Bays:
    2 x M.2 (BOSS-S2)
  • Dimensions:
    Height: 42.8mm (1.7”)
    Width: 434.0mm (17.1”)
    Depth: 736.54mm (29”)
    Weight: 21.8kg (48.06lbs)
  • Embedded Management:
    iDRAC9
    iDRAC RESTful API with Redfish
    iDRAC Direct
    Quick Sync 2 BLE/wireless module
  • OpenManage™ Software:
    OpenManage Enterprise
    OpenManage Power Manager
    OpenManage Mobile
  • Integrations and Connections:
    OpenManage Integrations:
    BMC Truesight
    Microsoft® System Center
    Red Hat® Ansible® Modules
    VMware vCenter

    OpenManage Connections:
    IBM Tivoli® Netcool/OMNIbus
    IBM Tivoli® Network Manager IP Edition
    Micro Focus® Operations Manager
    Nagios® Core
    Nagios® XI
    Micro Focus® Operations Manager I
    Nagios® Core
    Nagios® XI
  • Embedded NIC:
    2 x 1 GbE LOM ports
  • Networking Options (NDC):
    OCP x16 Mezz 3.0 + 2 x 1GE LOM
  • Security:
    Cryptographically signed firmware
    Secure Boot
    Secure Erase
    Silicon Root of Trust
    System Lockdown
    TPM 1.2/2.0, TCM 2.0 optional
  • Bezel:
    Optional LCD or Security Bezel
  • GPU Options:
    Up to 2 Single-Wide GPU
  • Ports:
    Front Ports:
    1 x Dedicated iDRAC direct micro-USB
    1 x USB 2.0
    1 x VGA

    Rear Ports:
    1 x Dedicated iDRAC network port
    1 x Serial (optional)
    1 x USB 3.0
    1 x VGA

    Internal:
    1 x USB 3.0 (optional)
  • PCIe:
    3 x Gen4 slots (x16) at 16GT/s
  • Supported Operating Systems:
    ESXi 9.1 - U1
    Red Hat Enterprise Linux 9
    Red Hat® Enterprise Linux 7
    Red Hat® Enterprise Linux 8
    SuSE Linux ES 15
    Ubuntu Server 20.04 LTS
    Ubuntu Server 22.04 LTS
    Ubuntu Server 24.04 - U3
    Ubuntu® Server 18.04 LTS
    VMware ESXi 6.5
    VMware ESXi 6.7
    VMware ESXi 7.0
    VMware ESXi 8.0
    VMware ESXi 9.0
    Windows Server 2016
    Windows Server 2019 LTSC
    Windows Server 2022 LTSC
    Windows Server 2025 LTSC
