Dell PowerEdge R540 Server

Tech Specs

• Base:
  PowerEdge R540 Server
• Processor:
  Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 20 cores per processor
• Memory:
  16 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666MT/s, 1TB max
• Fans:
  Up to six fans
• Storage Controllers:
  Internal controllers: PERC H750, H350, H740P, H730P, H330
  External controllers: HBA355e, H840, 12Gb/s Ext SAS HBA
  Software RAID: S140
  SAS Host Bus Adapters: HBA350i, HBA330
  Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB or 480GB
  Internal Dual SD Module²
• Drive Bays:
  Front drive bays: Up to 12 x 3.5” SAS/SATA HDD max 168TB
  Rear drive bays: Up to 2 x 3.5 SAS/SATA HDD max 28TB
  Optional DVD-ROM, DVD+RW
• Sizing:
  Form Factor: 2U Rack Server
  Height: 86.8mm (3.41”)
  Width*: 434mm (17.08”)
  Depth*: 693.81mm (27.31”)
  Weight: 29.68kg (65.43lbs.)
  *Dimensions do not include bezel.
• Bezel:
  Optional LCD or security bezel
• Embedded/At-Server:
  iDRAC9
  iDRAC Direct
  iDRAC REST API with Redfish
  Quick Sync 2 BLE/wireless module
• Consoles & Mobile:
  OpenManage Enterprise
  OpenManage Essentials
  OpenManage Mobile
  OpenManage Power Center
• Integrations:
  OpenManage integrations: Microsoft® System Center, VMware® vCenter™, BMC Truesight, Red Hat® Ansible® Modules
• Connections:
  Nagios® Core and Nagios® XI, IBM Tivoli® Netcool/OMNIbus
  Micro Focus Operations Manager I
• Tools:
  Dell EMC Repository Manager
  Dell EMC Update Package
  Dell EMC System Update
  Dell EMC Server Update Utility
  iDRAC Service Module
  OpenManage Server Administrator
  OpenManage Storage Services
• Power Supplies:
  Platinum 495W, 750W, 1100W
  Hot plug power supplies with full redundancy option
• Security:
  TPM 1.2/2.0, TCM 2.0 optional
  Cryptographically signed firmware
  Silicon Root of Trust
  Secure Boot
  System Lockdown (requires OpenManage Enterprise)
  System Erase
• I/O & Ports:
  Network options: 2 x 1GbE LOM + (optional) LOM Riser 2 x 1GbE or 2 x 10GbE SFP+ or 2 x 10GbE BaseT
  Front: 1 x Dedicated iDRAC Direct, 1 x USB 2.0, 1 x Video
  Rear: 1 x Dedicated iDRAC, 1 x Serial, 2 x USB 3.0, 1 x Video
  Optional Riser: Non-rear storage config: 1xFH/FL + 1xHH/HL (2U Right riser) slots + 3 HH/HL slots
  Rear storage config: 1xHH/HL (1U Left Riser) + 1xHH/HL (1U Right risers) slot or 1xHH/HL (1U Left Riser) + 1x FH/HL (1U Right riser)
• Supported Operating Systems:
  BIOS
  Citrix XenServer 7.1
  Red Hat Enterprise Linux 9
  Red Hat® Enterprise Linux 6
  Red Hat® Enterprise Linux 7
  Red Hat® Enterprise Linux 8
  SUSE Linux ES 12
  SuSE Linux ES 15
  Ubuntu Server 16.04 LTS
  Ubuntu Server 20.04 LTS
  Ubuntu® Server 18.04 LTS
  VMware ESXi 6.0
  VMware ESXi 6.5
  VMware ESXi 6.7
  VMware ESXi 7.0
  VMware ESXi 8.0
  Windows Server 2012 R2
  Windows Server 2016
  Windows Server 2019 LTSC
  Windows Server 2022 LTSC
