Dell PowerEdge VRTX

Tech Specs

• Base:
  PowerEdge VRTX
• Form Factor:
  Tower or 5U rack enclosure
• Weight & Dimensions:
  Tower configuration:
  H: 48.4 cm (19.1 in) w/ feet
  W: 31.0 cm (12.2 in) w/ feet opened
  D: 73.0 cm (28.7in)
  Weight (empty): 31.7 kg (69.7 lb)
  Weight (max): 74.8 kg (164.9 lb)

  Rack configuration:
  H: 21.9 cm (8.6 in)
  W: 48.2 cm (19.0 in)
  D: 73.0 cm (28.7 in)
  Weight (empty): 24.7 kg (54.5 lb)
  Weight (max): 68.7 kg (151.5 lb)
• Power Supplies:
  Redundant power supply units support 2+2 (AC redundancy) and 3+1 (power supply redundancy) modes
  US/Canada: 110/220V (typical)
  EU/China: 220-240V
  Japan: 100V/220V
  Other: Up to 240V
• Server Node Options:
  PowerEdge M640, M630 and M830
• Cooling Fans:
  PowerEdge VRTX comes standard with 6 hot-pluggable, redundant fan modules and 4 blower modules based on Dell Energy Smart Technologies. The fans and blowers deliver low-power consumption, but also use next-generation fan technologies to ensure the lowest possible amount of fresh air is consumed to cool the enclosure.
• Input Device:
  Front control panel with interactive graphical LCD:
  Front control panel with interactive graphical LCD that supports initial configuration wizard. It also supports local server blade, enclosure and module information and troubleshooting.
  Two USB keyboard/mouse connections and one video connection for local front “crash cart” console connections, optional DVD RW available.
• Drive Bays & Hard Drives:
  Up to 12 x 3.5” NLSAS, SAS or SAS SSD hot-plug drives or up to 25 x 2.5” NLSAS, SAS or SAS SSD hot-plug drives. Optional FIPS 140-2 certified self-encrypting drives (SED), up to 25 x 2.5 NLSAS, SAS or SAS SSD
• JBOD Expansion Options:
  Chassis storage can be expanded even further by connecting up to four MD1200 (12 x 3.5” drives) or MD1220 (24 x 2.5” drives) disk arrays
• Integrated Networking – Ethernet:
  Internal 1GbE 8-port pass-through module
  Internal 1GbE 24-port switch
  Internal 10GbE switch
• RAID Controller:
  iDRAC9
  Shared PERC8 with optional second redundant shared PERC8 available
• I/O Slots:
  8 PCIe Slots:
  3 full-height/full-length slots (150W) with double-wide card support (225W)
  5 low-profile/half-length slots (25W)
• Systems Management:
  Delivers comprehensive functionality yet simple and easy to use:
  Uses Chassis Management Controller to manage all resources (server nodes, storage, networking and power) with a unified management tool, presented in a single console
  Monitors up to 9 VRTX chassis from a single, consolidated CMC console
  Offers both local and remote management
  Available with either Enterprise or Express CMC licensing
  Redundant CMC available
  Server nodes each contain proven iDRAC with Lifecycle Controller for agent-free systems management, fully supported in the OpenManage product portfolio
• Rack Support:
  ReadyRails™ II sliding rails for 4-post racks with square, round or threaded holes
