Dell PowerEdge T560 Server

  • From: $6,883

xByte Technologies is a Dell Gold Partner and also sells Dell new (non-recertified) hardware.

  • 100% Dell Original Components
  • 30-Day Money-Back Guarantee
  • Dell Certified Technicians & Engineers
100% Satisfaction Guarantee - The xByte Difference
Dell Gold Partner Dell Outlet Platinum
Image of Dell PowerEdge T560 Server
  • Dell Server Generation:16th
  • Server Model:T560
  • Server Type:Tower
  • CPU:Up to two 4th or 5th Generation Intel Xeon Scalable processors with up to 32 cores per processor
  • Memory:16 DDR5 DIMM slots (Max 1.5TB)
  • RAID:PERC H355, PERC H755, PERC H755N, PERC H965i, HBA355i, HBA465i
  • HDD:3.5" and 2.5" Hot Swap SAS, SATA, Near Line SAS, and NVMe SSD
  • Power Supply:600W, 700W, 800W, 1100W, 1400W, 1800W, 2400W, 2800W Hot Swap Redundant
  • Riser:Up to 6 x PCIe Gen5/Gen4 slots
  • Rack Units:4.5U
SKU: >T560

Videos

Resources

Tech Specs

  • Base:
    PowerEdge T560 Server
  • Form Factor:
    4.5U Tower Server
  • Processor:
    Up to two 4th Generation Intel® Xeon Scalable processor, with up to 32 cores per processor
    Up to two 5th Generation Intel® Xeon Scalable processor, with up to 28 cores per processor
  • Dimensions:
    Height – 464.0 mm (18.26 inches)
    Width – 200.0 mm (7.87 inches)
    Depth – 678.2 mm (26.70 inches)
  • Power Supplies:
    600W Platinum 100-240 VAC/240 VDC
    700W Titanium 200-240 VAC/240 VDC
    800W Platinum 100-240 VAC/240 VDC
    1100W Titanium 100-240 VAC/240 VDC
    1100W DC/-48-(-60) V
    1400W Platinum 100-240 VAC/240 VDC
    1400W Titanium 100-240 VAC/240 VDC
    1400W Titanium 277 VAC/336 VDC
    1800 W Titanium 200-240 VAC/240 VDC
    2400 W Platinum 100-240 VAC/240 VDC
    2800 W Titanium 200-240 VAC/240 VDC
  • Memory:
    16 DDR5 DIMM slots, supports RDIMM 1.5 TB max
    Speeds up to 4800 MT/s on the 4th Generation Intel Xeon Scalable processor
    Speeds up to 5200 MT/s on the 5th Generation Intel Xeon Scalable processor
    Supports registered ECC DDR5 DIMMs only
  • Drive Bays:
    Up to 12 x 3.5-inch SAS/SATA HDD drives, max 180TB
    Up to 8 x 3.5-inch SAS/SATA HDD drives, max 120TB
    Up to 8 x 3.5-inch SAS/ SATA HDD + 8 x 2.5-inch NVMe SSD drives, max 240TB
    Up to 8 x 2.5-inch SAS/SATA HDD drives, max 120TB
    Up to 16 x 2.5-inch SAS/SATA HDD drives, max 240TB
    Up to 24 x 2.5-inch SAS/SATA HDD drives, max 360TB
  • Fans:
    Up to eight standard (STD) fans or high performance (HPR) fans
  • Cooling Options:
    Air cooling
  • Bezel:
    Optional security bezel
