Dell PowerEdge R720xd Server

Tech Specs

• Base:
  PowerEdge R720xd Server
• Form Factor:
  2U Rack Server
• Processor:
  Intel® Xeon® processor E5-2600 product family
• Processor Sockets:
  2
• Internal Interconnect:
  2 x Intel QuickPath Interconnect (QPI) links; 6.4 GT/s; 7.2 GT/s; 8.0 GT/s
• Cache:
  2.5MB per core; core options: 2, 4, 6, 8
• Chipset:
  Intel C600 series
• RAID Controllers:
  Internal:
  PERC H310
  PERC H710
  PERC H710P

  External HBAs (RAID):
  PERC H810

  External HBAs (non-RAID):
  6Gbps SAS HBA
• Memory:
  Up to 768GB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MHz
• Maximum Internal Storage:
  Up to 38TB
• Drive Bays:
  Up to twenty-six 2.5” drives or up to twelve 3.5” drives plus two 2.5” drives
• I/O Slots:
  6 PCIe slots:
  Two x16 full-length, full-height
  One x8 full-length, full-height
  Three x8 half-length, half-height
• Hard Drives:
  Hot-plug hard drive options:
  2.5” SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K)
  3.5” SAS (15K), nearline SAS (7.2K), SATA (7.2K)
  Self-encrypting drives available
• Availability:
  High-efficiency, hot-plug, redundant power supplies; hot-plug drive bays; TPM; dual internal SD support; hot-plug redundant fan; optional bezel; luggage-tag; ECC memory, interactive LCD screen; extended thermal support; ENERGY STAR® compliant, extended power range; Switch Independent Partitioning (SIP)
• Embedded NIC:
  Broadcom® Quad Port 1GbE BASE-T
  Intel Quad Port 1GbE BASE-T
  Intel Dual Port 10GbE BASE-T with 2 x 1GbE
  Broadcom Dual Port 10GbE SFP+ with 2 x 1GbE
• Power Supply:
  Platinum efficiency 495W, 750W or Platinum+ efficiency 1100W power supplies Auto-ranging power supplies
• Remote Management:
  iDRAC7 with Lifecycle Controller
  iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option)
  8GB or 16GB vFlash media (upgrade options)
• Systems Management:
  IPMI 2.0 compliant
  Dell OpenManage™ Essentials and Dell Management Console
  Dell OpenManage Power Center

  Dell OpenManage Connections:
  OpenManage Integration Suite for Microsoft® System Center
  Dell plug-in for VMware® vCenter™
  HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
• Rack Support:
  ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks)
• Operating System:
  Microsoft® Windows Server® 2008 R2 SP1, x64 (includes Hyper-V™ v2)
  Microsoft Windows® Small Business Server 2011
  SUSE® Linux® Enterprise Server
  Red Hat® Enterprise Linux

  Virtualization options:
  Citrix® XenServer™
  VMware vSphere™ ESX and ESXi
