Dell PowerVault MD2424

Call for price and availability

100% Satisfaction Guarantee - The xByte Difference
  • 100% Dell Original Components
  • 14 Day Money Back Guarantee
  • Dell Engineer Approved
Image of Dell PowerVault MD2424
  • Dell Server Generation:16th / 15th / 14th
  • Server Model:MD2424
  • Server Type:Rack
  • HDD:24 x 2.5" mixed-use and read-intensive SSD drives per enclosure
  • Power Supply:800W
  • HDD Capacity:Up to a maximum SSD capacity of 737.28TB, Up to a maximum HDD capacity of 230.4TB
  • Controller:2x 4-lane 24Gbps SAS host connect per EMM, 1x USB-C debug ports per EMM
  • Enclosure Management Modules:Enclosure Management Modules (EMM) 2 HA EMM per enclosure provide redundant enclosure management capability with iDRAC or SHMCLI
SKU: >MD2424

Videos

Resources

Tech Specs

  • Base:
    PowerVault MD2424 Storage Array
  • Form Factor:
    2U
  • Controllers:
    Dual 12Gbs/25Gbps SAS
  • Internal Storage:
    24 x 2.5” (14G/15G/16G)
  • Min/Max Drive Count:
    Up to 96 for HBA355e Up to 96 for H840 PERC Up to 96 for HBA355e
  • PERC Support:
    Yes
  • Max Enclosures:
    4 (with HBA355e) 4 (with H840 PERC) 4 (with HBA355e)
  • Max Raw Capacity:
    230.40TB (2.4TB 10K) 737.28TB (7.68TB SSD)
  • Storage Media:
    10K SAS/FIPS 2.5” drives - 2.4TB; 1.2TB; 600GB - FIPS: 2.4TB, 1.2TB SAS SSD/FIPS 2.5” (mixed use) - 1.6TB; 800GB - FIPS: 3.84TB; 1.92TB, 960GB SAS SSD/FIPS 2.5” (Read Intensive) - 7.68TB; 3.84TB; 1.92TB - FIPS: 7.68TB; 3.84TB; 1.92TB
  • Host Interface:
    12Gb/24Gb SAS
  • I/o & Ports:
    2x 4-lane 24Gbps SAS host connect per EMM (MD2412, MD2424) 4x 4-lane 24Gbps SAS host connect per EMM (MD2460) 1x USB-C debug ports per EMM
  • Expansion Protocol:
    24Gb SAS4
  • Supported:
    All-Flash, Hybrid Flash (10K HDD only (MD2424); 7.2K HDD only (MD2412, MD2460)
  • Management:
    Enclosure Management Modules (EMM) 2 HA EMM per enclosure provide redundant enclosure management capability with iDRAC or SHMCLI
  • PowerEdge Servers:
    14G/15G servers; R760, R660, R7625, R6625, R7615, R6615 servers
  • Dimensions:
    H: 86.8 mm (3.4 inches) W: 444.0 mm (17.5 inches) D: 545 mm (21.5 inches)
  • Weight:
    Max Config: 21.76 kg (49 lbs) Empty: 16 kg (35.27 lbs)
  • Power/Wattage:
    800W
  • Voltage:
    100-127/200-240 VAC; 240 VDC (China only)
  • Frequency:
    50/60 Hz
  • Operating temperature Operating temperature (ASHRAE A3):
    0ºC to 40ºC (32ºF to 104ºF) 5ºC to 40ºC (41ºF to 104ºF)
  • Non-operating temperature:
    -40ºC to +65ºC (-40ºF to +149ºF)
  • Operating humidity ranges (non-condensing):
    8% to 85% non-condensing
  • Non-operating humidity (non- condensing) :
    10% to 95% non-condensing
  • Operating max. temperature gradient:
    20ºC per hour
  • Service and Warranty:
    Dell ProSupport Enterprise Suite and Dell ProDeploy Enterprise Suite. Optional ProSupport Plus is available offering pro-active and preventative.
