Dell PowerEdge C6525 Server Node

Tech Specs

• Base:
  PowerEdge C6525
• Processor:
  One or two 2nd or 3rd Generation AMD EPYC Processors per node configurations with up to 64 cores per processor and up to 280W (TDP)
• Memory:
  Up to 16 x DDR4
  RDIMM 2TB Max
  LRDIMM 2TB Max
  Bandwidth up to 3200 MT/S
• Availability:
  Hot plug redundant Hard drives, Fans, PSUs
• Controllers:
  HW RAID: PERC 10.4 port for H745, H345, HBA345 Chipset
  SW RAID (S150): Yes
• Drive Bays:

  2.5” Direct Backplane configuration with up to 6 SAS/SATA drives per node, up to 24 per chassis
  2.5” NVMe Backplane configuration with up to 2 NVMe drives and 4 SAS/SATA drives per node.
  Up to 24 drives total per chassis
  3.5” Direct Backplane configuration with up to 3 SAS/SATA drives per node, up to 12 per chassis
  Internal: uSD card | M.2 SATA BOSS 1.0
• Embedded Management:
  iDRAC9
  iDRAC Direct
  iDRAC RESTful API with Redfish
• Dimensions & Weight:
  Height: 86.8mm (3.4”)
  Width: 448.0mm (17.6”)
  Depth: 790.0mm (31.1”)
  Weight:
  45.53kg (100.3lbs) 3.5” direct backplane chassis
  41.5kg (91.4lbs) 2.5” direct/NVMe backplane chassis
  35.15kg (77.4lbs) no backplane chassis
• Rack Units:
  2U/4N Rack Server
• OpenManage SW:
  OpenManage Enterprise
  OpenManage Enterprise Power Manager
  OpenManage Mobile
• OpenManage Integrations:
  BMC Truesight
  Microsoft® System Center
  Redhat® Andible® Modules
  VMware® vCenter™
• OpenManage Connections:
  IBM Tivoli® Netcool/OMNIbus
  IBM Tivoli® Network Manager IP Edition
  Micro Focus® Operations Manager I
  Nagios® Core
  Nagios® XI
• Security:
  Cryptographically signed firmware
  Secure Boot
  Secure Erase
  Silicon Root of Trust
  System Lockdown
  TPM 1.2/2.0, TCM 2.0 optional
• Fans:
  Hot plug Fans
• Power Supplies:
  Dual Hot-plug redundant 2000W and 2400W AC
  Dual Hot-plug redundant 2000W AC/DC Mixmode
  Cooling options: Air Cooling, Direct Liquid Cooling (DLC)
• Embedded NIC:
  Single port 1GbE LOM
• Networking Options (NDC):
  1x OCP 3.0
• GPU Options:
  1x Single-Wide GPU
• Rear Ports:
  1 x iDRAC Direct micro-USB port
  1 x Mini-display port
  1 x iDRAC or NIC port
  1 x USB 3.0 port
• PCIe:
  2x PCIe x16 Gen4 Risers
  1x OCP 3.0 x16 Gen4
  1x PCIe x8 Gen3 M.2 Riser
• Operating Systems & Hypervisors:
  Canonical® Ubuntu® Server LTS
  CentOS based on RHEL 8.0 Kernel
  Citrix® Hypervisor
  Microsoft® Windows Server® with Hyper-V
  Red Hat® Enterprise Linux
  SUSE® Linux Enterprise Server
  VMware® ESXi®
