Dell PowerEdge R620 Servers

Dell PowerEdge R620
The xByte Difference
Need help with a configuration? Contact us at 888-929-8348 - or through our online Live Chat above - to speak directly to our knowledgeable team.

Manufacturer: Dell
Brand: PowerEdge
Model: R620

PowerEdge R620 is a 2-socket rack server with the latest server processing technology combining substantial power in space sensitive 1U design. Using the latest Intel Xeon E5 processors with up to 24 dimms and the latest I/O capabilities the R620 is a flexible general purpose rack server.
Form Factor 1U rack
Processors Intel® Xeon® processor E5-2600 product family
Processor Sockets 2
Internal interconnect 2 x Intel QuickPath Interconnect (QPI) links: 6.4 GT/s, 7.2 GT/s, 8.0 GT/s
Cache 2.5MB per core; core options: 2, 4, 6, 8
Chipset Intel C600
Memory Up to 768GB (24 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
I/O Slots 3 PCIe slots: (10-drive-bay configuration is available only with the 3 PCIe slot option); Two x16 slots with x16 bandwidth, half-height, half-length; One x16 slot with x8 bandwidth, half-height, half-length; or 2 PCIe slots: One x16 slot with x16 bandwidth, full-height, 3/4 length; One x16 slot with x16 bandwidth (or x8 with one processor only), half-height, half-length
RAID Controller Internal controllers: PERC S110 (SW RAID); PERC H310; PERC H710; PERC H710P; External HBAs (RAID): PERC H810; External HBAs (non-RAID): 6Gbps SAS HBA
Drive Bays Up to ten 2.5” hot-plug SAS, SATA, or SSD or up to four hot-plug 2.5” SAS, SATA, or SSD + two PCIe SSD
Maximum Internal Storage Up to 10TB
Hard Drives Hot-plug hard drive options: 2.5” PCIe SSD, SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K); Self-encrypting drives available
Embedded NIC Broadcom® 5720 Quad Port 1GbE BASE-T (no TOE or iSCSI offload); Intel I350 Quad Port 1GbE BASE-T (no TOE or iSCSI offload); Intel X540 Dual Port 10GbE BASE-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports); Broadcom 57800S Dual Port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports; Broadcom 57800S Dual Port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports
Power supply Auto-ranging Titanium efficiency, hot-plug redundant 750W AC power supply; Auto-ranging Platinum efficiency, hot-plug redundant 495W, 750W or 1100W AC power supply; 1100W DC power supply
Availability High-efficiency, hot-plug, redundant power supplies; hot-plug hard drives; TPM; dual internal SD support; hot-plug, redundant fans; optional bezel; information tag; ECC memory; interactive LCD screen; extended thermal support; ENERGY STAR® compliant; switch independent partitioning
Remote management iDRAC7 with Lifecycle Controller; iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option),; 8GB vFlash media (upgrade option), 16GB vFlash media (upgrade option)
Systems management IPMI 2.0 compliant; Dell OpenManage™ Essentials and Dell Management Console; Dell OpenManage Power Center; Dell OpenManage Connections:
  • OpenManage Integration Suite for Microsoft® System Center
  • Dell plug-in for Vmware® vCenter™
  • HP Operations Manager, IBM Tivoli® Netcool® , and CA Network and Systems Management
Rack support
  • ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
  • ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks
Operating systems Microsoft® Windows Server® 2012; Microsoft Windows Server 2012 Essentials; Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V® v2); Microsoft Windows® Small Business Server 2011; Novell® SUSE® Linux Enterprise Server; Red Hat® Enterprise Linux®; Virtualization options: Citrix® XenServer®; Vmware vSphere® including ESX™ and ESXi™; Red Hat Enterprise Virtualization® For more information on the specific versions and additions, visit Dell.com/Ossupport.


Dell PowerEdge R620 Server ( 2 CPU Version ) w/xByte Warranty

  • CPU(s):  2 x Intel E5 Multi Core
  • Memory: 24 DIMM Slots (Max 768GB)
  • RAID: PERC H310, PERC H710 512MB NV, PERC H710p 1GB NV
  • HDD:  2.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER:3 PCIe Slots (Half Height) or 2 PCIe Slots (1 Full Height, 1 Half Height)
  • Power: 495W or 750W or 1100W Hot Swap Redundant
  • Condition:  Refurbished
  •
  • Starting at $999.00
  • was $2,999.00
  • save $2,000.00
  • Custom Configuration
xByte holds an unwavering commitment to delivering the highest quality customer service and products. Our diverse stock, including the Dell PowerEdge R620, is ready to be packed and shipped at a moment’s notice, making us one of the few refurbished Dell PowerEdge R620 server suppliers who can ship within 24-hours of order.

Our Dell PowerEdge R620 Warranty

Purchasing a Dell PowerEdge R620 from xByte isn’t much of a gamble, because not only is this a fantastic Dell server, but we also provide a 14-day no questions asked return policy. In addition to this lengthy return period, we are also happy to offer an industry leading warranty, because we stand by the quality of our Dell PowerEdge R620 servers. Learn about our warranty policy by clicking here.

Certifed Technicians

Our technicians have all been trained by Dell to understand the specific details of the Dell PowerEdge R620 server and they are an important part of our unique equation for success. Every employee at xByte understands that our success hinges on providing great customer service and an amazing customer experience, which is why our technicians are happy to assist with any of your setup or troubleshooting needs for your Dell PowerEdge R620 server.

Customer Friendly Purchase Policy

xByte’s business model and environmental stability go hand in hand. We are happy to purchase our customers used, outdated or off-lease IT equipment in order to refurbish it and resell it on the market, like our Dell PowerEdge R620 servers. Thank you from us and the environment for your contribution to the best server recycling possible.

Whether you’re looking for a Dell PowerEdge R620 server or one of our other high quality products, you will not be disappointed. xByte Technologies is ready to help you find the IT equipment that makes the most sense for your unique needs.
