Dell PowerEdge R310 Servers

Dell PowerEdge R310
The xByte Difference
The Dell™ PowerEdge™ R310 is a high-performance, one-socket 1U rack server with the right computing power, business scalability, simplified management, data protection and security features to make it an ideal choice for small to midsize businesses, remote offices and enterprises.

CPU(s): 1 x Intel Xeon 3400 series
Memory: 4 DIMM Slots (Max 16GB)
RAID: SAS6ir, H200, Perc6i or H700
HDD: 3.5" Hot Swap SAS, SATA and Near Line SAS
RISER: 1xPCI-E
Power: 2x400W Hot Swap
Form factor 1-Socket 1U Rack
Processors Intel® Xeon® processor X3400 series; Intel® Xeon® processors L3400 series; Intel® Core™ processor i3-500 series; Intel® Pentium® processor G6950; Intel® Celeron® processor G1101
Processor Socket 1
Cache 2,3,4 and 8MB
Chipset Intel® 3420 Chipset
Memory Up to 32GB (6 DIMM slots) 1GB/2GB/4GB/8GB 1066 & 1333MHz
I/O Slots 2 PCIe G2 slots: Slot 1: PCIe x16 (x8 routing), Full Height/Half Length; Slot 2: PCIe x8 (x8 routing), Full Height /Half Length
RAID Controller Internal Controllers: 6Gb/s SAS HBA; PERC H200 (6Gb/s); PERC H700 (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache; SAS 6/iR; PERC S100 (software based); PERC S300 (software based); External Controllers: PERC H800 (6Gb/s) with 512MB of battery-backed; cache;512MB, 1GB Non-Volatile battery-backed cache; 6Gbs SAS HBA X8 External HBAs (non-RAID): 6Gbps SAS HBA ; Brocade®FC4 and 8GB HBAs; LSI2032
Drive Bays Cabled or hot-swap options available: 4 hard drive chassis: 3.5” SAS and SATA or 2.5” SAS and SSD drives
Maximum internal storage Up to 8TB
Hard Drives 3.5” cabled SATA (7.2K RPM): 160GB, 250GB, 500GB, 1000GB, 2000GB; 3.5” cabled Near Line SAS (7.2K RPM): 500GB, 1000GB, 2000GB; 3.5” hot-swap SAS (15K RPM): 146GB, 300GB, 450GB, 600GB, (10K RPM) 600GB; 3.5” hot swap SAS (10K RPM) 600GB; 3.5” 6Gps SAS (7.2K): 2TB; 2.5” hot-swap SAS (10K RPM): 146GB, 300GB; 2.5” hot-swap SSD 50GB, 100GB; 2.5” (7.2K) Nearline SAS: 1TB
Communications Intel® Gigabit ET Quad Port Server Adapter; Intel® Gigabit ET Dual Port Server Adapter; Broadcom® NetExtreme™ II 5709 Dual-Port Gb Ethernet TOE Server Adapter; Broadcom® NetExtreme™ II 5709 Dual-Port Gb Ethernet TOE/iSCSI Offload Server Adapter; Intel® PRO/1000 PT Server Adapter; Brocade® CNA Dual-port adapter; Optional Add-In HBAs: Brocade® FC4 and 8 GB HBAs
Power Supply One non-redundant 350W power supply; Two hot-pluggable redundant 400W hot-plug power supplies
Availability Hot-plug hard drives, hot-plug redundant power supplies, DDR3 ECC memory, and quad-pack LED or an interactive LCD display screen
Video Matrox® G200eW w/ 8MB
Remote Management Optional iDRAC Express,iDRAC 6 Enterprise
Systems Management Full OpenManage™ Support: BMC, IPMI2.0 compliant; Lifecycle Controller enabled via optional: iDRAC6 Express, iDRAC6 Enterprise and vFlash
Rack Support ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks); ReadyRails™ static rails for 2-post and 4-post rack
Operating Systems Microsoft® Windows® Essential Business Server 2008; Microsoft® Windows Server®2008 SP2, x86/x64 (x64 includes Hyper-V™); Microsoft® Windows Server®2008 R2, x64 (includes Hyper-V™ v2); Microsoft® Windows® HPC Server 2008; Novell® SUSE® Linux® Enterprise Server; Red Hat® Enterprise Linux®; Solaris™ 10 05/10 (update 10) x86-64; Optional Embedded Hypervisors: Citrix® XenServer™ Enterprise 5.6 x86-64; VMware® vSphere™ 4.1 (including VMware ESX®4.1 or VMware ESXi™ 4.1); Vizioncore™ vEssentials; Novell® PlateSpin® Migrate;


Dell PowerEdge R310 ( Hot Swap Power Supplies )

Dell PowerEdge R310 ( Hot Swap Power Supplies )

  • CPU(s):  1 x Intel Xeon 3400 series
  • Memory: 6 DIMM Slots (Max 32GB)
  • RAID: SAS6ir, H200, Perc6i or H700
  • HDD:  3.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER: 1xPCI-E
  • Power: 2x400W Hot Swap
  • Condition:  Used
  •
  • Starting at $899.00
  • was $1,199.00
  • save $300.00
  • Custom Configuration
