Form factor
|
7U rack-mount enclosure holds up to ten blade servers
|
|
Dimensions (H x W x D) |
30.67cm (12.07") H x 44.60cm (17.56") W x 73.50cm (28.94") D
|
|
Power Supplies
|
Hot-pluggable, non-redundant or optional 2+2 redundant power
|
|
Input devices
|
Integrated Avocent® Analog or Digital Access keyboard, video and mouse (KVM) switch
with seamless tiering into an external Avocent or Dell switch environment
|
|
Enclosure I/O modules
|
PowerConnect™ 5316M Ethernet Switch, Ethernet Pass-Through, Fibre Channel
Pass-Through, Brocade® Silkworm® 4016 Fibre Channel Switch McDATA® 4416 Fibre
Channel Switch or Topspin® InfiniBand Pass-Through
|
|
Processors
|
Up to two Quad-Core Intel Xeon 5300 sequence processors at up to 2.66GHz;
Up to two Dual-Core Intel Xeon 5100 sequence processors at up to 3.0GHz;
Up to two Dual-Core Intel Low Volt Xeon 5148 processor at 2.33GHz;
Up to two Dual-Core Intel Xeon 5000 sequence processors at up to 3.0GHz
|
|
Front side bus
|
Intel Xeon 5300 Sequence: Dual Independent 1066MHz or 1333MHz;
Intel Xeon 5100 Sequence: Dual Independent 1066MHz or 1333MHz;
Intel Xeon 5000 Sequence: Dual Independent 667MHz
|
|
Cache
|
Intel Xeon 5300 Sequence: 2x4MB;
Intel Xeon 5100 Sequence: 4MB;
Intel Xeon 5000 Sequence: 2x2MB
|
|
Chipset
|
Intel 5000P
|
|
Memory
|
Up to 32GB (8 FBD DIMM slots) 256MB/512MB/1GB/2GB/4GB Fully Buffered DIMMs (FBD)
in matched pairs, 533MHz or 667MHz
|
|
I/O slots
|
Optional daughtercard and I/O modules for Fibre ChannelSAN, Ethernet and InfiniBand
|
|
Drive controller
|
SAS 5/iR (H/W based) with RAID 1 support
|
|
Drive bays
|
Two 2.5" SAS/SATA drives
|
|
Maximum internal storage
|
Up to 146GB: two 73GB hot-plug 2.5” SAS (10K RPM);
Up to 80GB: two 40GB hot-plug 3.5” SATA (5.4K RPM)
|
|
Hard drives2
|
2.5” SAS (10K RPM): 36GB, 73GB;
2.5” SATA (5.4K RPM): 40GB
|
|
Internal storage
|
2 x 2.5" hot-plug SAS (10K RPM) or SATA (5.4K RPM) drives
|
|
External storage
|
Fibre channel storage systems
|
|
Tape backup options
|
SAN-based or LAN-based backup
|
|
Network interface card
|
Dual port embedded Broadcom® NetXtreme II™ 5708 Gigabit1 Ethernet NIC with load
balancing and failover; TOE (TCPIP Offload Engine) supported on Microsoft Windows
Server 2003, SP1 or higher with Scalable Networking Pack
|
|
Power supply
|
2+2, 2100W, hot-pluggable redundant power
|
|
Availability
|
ECC FBD memory and SDDC (Single Device Data Correction) support; optional hot-plug redundant
power, cooling and I/O modules; dual embedded NICs with failover and load balancing support;
optional redundant Ethernet switches and other I/O technologies; validated for Dell/EMC SAN,
Optional management redundancy with DRAC/MC
|
|
Video
|
Embedded ATI ES1000 with 16MB memory
|
|
Remote management
|
Baseboard Management Controller with IMPI 2.0 support; DRAC/MC chassis management
module; virtual media; dynamic DNS
|
|
Systems management
|
Dell OpenManage™
|
|
Rack support
|
24U or 42U Dell rack; non-sliding Versa & Rapid rails
|
|
Operating systems
|
Microsoft® Windows® Server 2003, Standard, Enterprise, Web Edition; Red Hat® Linux®
Enterprise v4 (ES, AS and WS); SUSE Linux Enterprise Server 10
|
