Dell PowerEdge R910 Servers

Dell PowerEdge R910
The xByte Difference
The PowerEdge R910 is an Intel processor-based 4-socket, 4U rack server for mission-critical applications in corporate data centers and workloads needing the highest performance, reliability and I/O scalability.

CPU(s): 4 x Intel 7500 Multi Core
Memory: 64 DIMM Slots (Max 1TB)
RAID: H700
HDD: 2.5" Hot Swap SAS, SATA and Near Line SAS
RISER: 7xPCI-E
Power: 750W or 1100W Hot Swap
Form Factor 4U rack-mount
Processors Up to Four Intel® Xeon® processors 7500 Quad-, Six, or Eight-Core series
Processor Sockets 4
Front Side Bus or HyperTransport Intel® QuickPath Interconnect (QPI)
Cache Up to 24MB
Chipset Intel® 7500 Chipset
Memory Up to 1TB (64 DIMM slots) 1GB/2GB/4GB/8GB/16GB DDR3 1066MHz
I/O Slots Up to 10 PCIe G2* Slots: Standard: 7 PCIe Gen2* slots (2 x4, 4 x8, 1 x16); Optional: 10 PCIe Gen2* (6 x4, 4 x8); One storage x8 slot; *slot5 is x4 PCIe Gen1 slot
RAID Controller Internal controllers: PERC H200 (6Gb/s); PERC H700 (6Gb/s) with 512MB battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache External controllers: PERC H800 (6Gb/s) with 512MB of battery-backed cache; 512MB, 1GB Non-Volatile battery-backed cache External HBAs (non-RAID): 6Gbps SAS HBA; SAS 5/E HBA; LSI2032 PCIe SCSI HBA
Drive Bays Hot-Swap Options Available: Up to sixteen 2.5” SAS, SSD
Maximum Internal Storage Up to 4.8TB
Hard Drives 2.5” (10K) SATA SSD: 50GB; 2.5” SAS (10K) 146GB, 300GB, 600G
Communications Embedded NICs: 1GbE or 10Gb embedded NIC options with iSCSI offload; 2x Broadcom® 5709c (4 ports x 1GbE Base-T Copper) Embedded NIC or Broadcom® 57711 (2 ports x 10Gb SFP+) and Broadcom® 5709c (2 ports x 1GbE Base-T Copper) Embedded NIC Optional NICs: Broadcom® 57710 Single Port 10GbE NIC, Copper CAT6 PCIe-8; Intel®DA 10GbE NIC, Dual Port, Optical, PCIe-8; Intel®10GbE Single Port 10GbE NIC, Copper, PCIe-8; Broadcom® NetXtreme® II 5709 Gigabit NIC w/TOE & iSOE, Quad Port, Copper, PCIe-4; Broadcom® 5709 Dual Port 1GbE NIC w/TOE PCIe-4, Low Profile; Broadcom® 5709 Dual Port 1GbE NIC w/TOE iSCSI, PCIe-4, Low Profile; Broadcom® 5709 Dual Port 1GbE NIC w/TOE iSCSI, PCIe-4 Broadcom® NetXtreme® II 5709 Gigabit NIC w/TOE & iSOE, Quad Port, Copper, PCIe-4, Low Profile; Broadcom® 5709 Dual Port 1GbE NIC w/TOE PCIe-4 Broadcom® NetXtreme® II 57711 10GbE NIC w/TOE & iSOE, Dual Port, SFP+, PCIe-8; Intel® Gigabit ET NIC, Dual Port, Copper, PCIe-4, Low Profile; Intel® Gigabit ET Dual Port NIC, PCIe-4 Intel® Gigabit ET NIC, Quad Port, Copper, PCIe-4, Low Profile; Broadcom® 5709 Dual Port 1GbE NIC w/TOE PCIe-4, Low Profile; Intel® Gigabit ET Quad Port NIC, PCIe-4; Brocade® CNA Dual-port adapter; Emulex® CNA iSCSI HBA stand up adapter OCE10102-IX-D; Brocade® CNA BR1020
Power Supply Hot-plug redundant PSUs: 4 x 750W (Energy Smart PSU) (or) 4 x 1100W (High Output PSU)
Availability Hot-plug hard drives, Hot-plug redundant power, Hot-plug redundant fans, ECC memory, Internal dual SD Module, redundant cooling
Video Matrox® G200eW w/ 8MB memory
Remote Management iDRAC6 Express; iDRAC 6 Enterprise with vFlash optional
Systems Management BMC, IPMI2.0 compliant; Dell™ OpenManage™ featuring Dell Management Console; Unified Server Configurator; Lifecycle Controller enabled via optional iDRAC6 Express, iDRAC6 Enterprise, and vFlash; Microsoft® System Center Essential (SCE) 2010 v
Rack Support ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks)
Operating Systems Microsoft® Windows® Essential Business Server 2008; Microsoft® Windows Server® 2008 SP2, x86/x64 (x64 includes Hyper-V™); Microsoft® Windows Server® 2008 R2, x64 (includes Hyper-V™ v2); Microsoft® Windows®HPC Server 2008; Novell® SUSE® Linux® Enterprise Server; Red Hat® Enterprise Linux® Optional Embedded Hypervisor: VMware® vSphere™ 4.1 (including VMware ESX® 4.1 or VMware ESXi™ 4.1); For more information on the specific versions and additions, visit www.dell.com/OSsupport.
Featured Database Applications Microsoft® SQL Server® solutions (see Dell.com/SQL); Oracle® database solutions (see Dell.com/Oracle)


Dell PowerEdge R910 ( 2 CPU Version )

Dell PowerEdge R910 ( 2 CPU Version )

  • Warranty:  Remainder of Dell's 3 Year Next Business Day Warranty
  • CPU(s):  2 x Intel 7500 Multi Core
  • Memory: 32 DIMM Slots (Max 256GB)
  • RAID: H700
  • HDD:  2.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER: 7xPCI-E
  • Power: 750W or 1100W Hot Swap
  • Power Config: 2 ("Full") or 2+2 ("Full Redundant")
  • Condition:  Refurbished
  •
  • Starting at $2,999.00
  • was $9,999.00
  • save $7,000.00
  • Custom Configuration
Dell PowerEdge R910 ( 4 CPU Version )

Dell PowerEdge R910 ( 4 CPU Version )

  • Warranty:  Remainder of Dell's 3 Year Next Business Day Warranty
  • CPU(s):  4 x Intel 7500 Multi Core
  • Memory: 64 DIMM Slots (Max 1TB)
  • RAID: H700
  • HDD:  2.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER: 7xPCI-E
  • Power: 750W or 1100W Hot Swap
  • Power Config: 2 ("Full") or 2+2 ("Full Redundant")
  • Condition:  Refurbished
  •
  • Starting at $3,999.00
  • was $11,999.00
  • save $8,000.00
  • Custom Configuration
