Dell PowerEdge R720xd Servers

Dell PowerEdge R720xd
The xByte Difference
The PowerEdge R720xd packs very dense storage capabilities in to a 2 socket, 2U form factor. Supporting Intel Xeon E5 processors, backed by up to 24 dimms for processing large amounts of data. With an internal disk capacity of up to 26x2.5” hard drives, the R720xd is ultra-powerful and ultra-scalable.

Need help with a configuration? Contact us at 888-929-8348 - or through our online Live Chat above - to speak directly to our knowledgeable team.

CPU(s): 2 x Intel E5 Multi Core
Memory: 24 DIMM Slots (Max 768GB)
RAID: PERC H310, PERC H710 512MB NV, PERC H710p 1GB NV
HDD: 2.5" or 3.5" Hot Swap SAS, SATA and Near Line SAS
RISER: 3 x FH, 3 x HH PCI-E Slots
Power: 495W or 750W or 1100W Hot Swap Redundant
Form Factor 2U rack
Processors Intel® Xeon® processor E5-2600 product family
Processor Sockets 2
Internal interconnect 2 x Intel QuickPath Interconnect (QPI) links; 6.4 GT/s; 7.2 GT/s; 8.0 GT/s
Cache 2.5MB per core; core options: 2, 4, 6, 8
Chipset Intel C600
Memory Up to 768GB (24 DIMM Slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
I/O Slots 6 PCIe slots:
  • Two x16 full-length, full-height
  • One x8 full-length, full-height
  • Three x8 half-length, half-height
RAID Controller Internal controllers: PERC H310; PERC H710; PERC H710P; External HBAs (RAID): PERC H810
Drive Bays Up to twenty-six 2.5” drives or up to twelve 3.5” drives plus two 2.5” drives
Maximum Internal Storage Up to 50TB
Hard Drives Hot-plug hard drive options: 2.5” SAS SSD, SATA SSD, SAS (15K, 10K), nearline SAS (7.2K), SATA (7.2K); 3.5” SAS (15K), nearline SAS (7.2K), SATA (7.2K); Self-encrypting drives available
Embedded NIC Broadcom® 5720 Quad Port 1GbE BASE-T (no TOE or iSCSI offload); Intel I350 Quad Port 1GbE BASE-T (no TOE or iSCSI offload); Intel X540 Dual Port 10GbE BASE-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports); Broadcom® 57800S Dual Port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports; Broadcom 57800S Dual Port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports
Power supply Auto-ranging Titanium efficiency, hot-plug redundant 750W AC power supply; Auto-ranging Platinum efficiency, hot-plug redundant 495W, 750W or 1100W AC power supply; 1100W DC power supply
Availability High-efficiency, hot-plug, redundant power supplies; hot-plug drive bays; TPM; dual internal SD support; hot-plug, redundant fan; optional bezel; information tag; ECC memory; extended thermal support; ENERGY STAR® compliant; switch independent partitioning
Remote management iDRAC7 with Lifecycle Controller; iDRAC7 Express (default), iDRAC7 Enterprise (upgrade option); 8GB or 16GB vFlash media (upgrade options)
Systems management IPMI 2.0 compliant; Dell OpenManage™ Essentials and Dell Management Console; Dell OpenManage Power Center; Dell OpenManage Connections:
  • Dell OpenManage Integration Suite for Microsoft® System Center
  • Dell plug-in for Vmware® vCenter™
  • HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
Rack support
  • ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm
  • ReadyRails static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks
Operating systems Microsoft® Windows Server® 2012; Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V® v2); Microsoft Windows® Small Business Server 2011; Novell® SUSE® Linux Enterprise Server; Red Hat® Enterprise Linux®; Virtualization options: Citrix® XenServer®; Vmware vSphere® including ESX™ and ESXi™; Red Hat Enterprise Virtualization® For more information on the specific versions and additions, visit Dell.com/Ossupport.


Dell PowerEdge R720xd Server ( 2 CPU Version ) w/xByte Warranty

Dell PowerEdge R720xd Server ( 2 CPU Version ) w/xByte Warranty

  • CPU(s):  2 x Intel E5 Multi Core
  • Memory: 24 DIMM Slots (Max 768GB)
  • RAID:PERC H710 512MB NV, PERC H710p 1GB NV
  • HDD:  2.5" or 3.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER:6 PCIe Slots (3 Full Height, 3 Half Height)
  • Power: 495W or 750W or 1100W Hot Swap Redundant
  • Condition:  xByte Recertified
  • Warranty:  1 Year xByte Warranty
  •
  • Starting at $1,549.00
  • was $4,399.00
  • save $2,850.00
  • Custom Configuration

xByte holds an unwavering commitment to delivering the highest quality customer service and products. Our diverse stock, including the Dell PowerEdge R720xd, is ready to be packed and shipped at a moment’s notice, making us one of the few refurbished Dell PowerEdge R720xd server suppliers who can ship within 24-hours of order.

Our Dell PowerEdge R720xd Warranty

Purchasing a Dell PowerEdge R720xd from xByte isn’t much of a gamble, because not only is this a fantastic Dell server, but we also provide a 14-day no questions asked return policy. In addition to this lengthy return period, we are also happy to offer an industry leading warranty, because we stand by the quality of our Dell PowerEdge R720xd servers. Learn about our warranty policy by clicking here.

Certifed Technicians

Our technicians have all been trained by Dell to understand the specific details of the Dell PowerEdge R720xd server and they are an important part of our unique equation for success. Every employee at xByte understands that our success hinges on providing great customer service and an amazing customer experience, which is why our technicians are happy to assist with any of your setup or troubleshooting needs for your Dell PowerEdge R720xd server.

Customer Friendly Purchase Policy

xByte’s business model and environmental stability go hand in hand. We are happy to purchase our customers used, outdated or off-lease IT equipment in order to refurbish it and resell it on the market, like our Dell PowerEdge R720xd servers. Thank you from us and the environment for your contribution to the best server recycling possible.

Whether you’re looking for a Dell PowerEdge R720xd server or one of our other high quality products, you will not be disappointed. xByte Technologies is ready to help you find the IT equipment that makes the most sense for your unique needs.
