Dell PowerEdge R320 Servers

Dell PowerEdge R320
The xByte Difference
The Dell PowerEdge R320 is an enterprise-class, 1-socket server, with the right computing power, scalability and value in a dense chassis — ideal for your core business applications.

Need help with a configuration? Contact us at 888-929-8348 - or through our online Live Chat above - to speak directly to our knowledgeable team.

CPU(s): 1 x Intel E5 Multi Core
Memory: 6 DIMM Slots (Max 96GB)
RAID: PERC H310, PERC H710 512MB NV
HDD: 2.5" or 3.5" Hot Swap SAS, SATA and Near Line SAS
RISER: 2 PCIe Slots (1 Full Height, 1 Half Height)
Power: 350W or 550W Hot Swap Redundant
Form Factor 1U rack
Processors Intel® Xeon® processor E5-2400 product family; Intel Xeon processor E5-1410; Intel Pentium® processor 1400 product family
Processor Sockets 1
Internal interconnect Intel DMI 2.0
Cache 2.5MB per core; core options: 2, 4, 6, 8
Chipset Intel C600 series
Memory Up to 192GB (6 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
I/O Slots 2 PCIe slots:
  • One x8 PCIe slot with x4 bandwidth, 2.0, half-length, half-height
  • One x16 PCIe slot with x16 bandwidth, 3.0, half-length, full-height
RAID Controller Internal controllers: PERC S110 (SW RAID); PERC H310; PERC H710; External HBAs (RAID): PERC H810; External HBAs (non-RAID): 6Gbps SAS HBA
Drive Bays Up to eight 2.5” hot-plug SAS, SATA or SSD or four 3.5” SAS, SATA
Maximum Internal Storage Up to 16TB
Hard Drives Hot-plug hard drive options: 2.5” SATA, nearline SAS, SAS (15K, 10K), SAS SSD, SATA SSD; 3.5” SATA, nearline SAS, SAS (15K); Cabled hard drive options: 3.5” SATA, nearline SAS, SAS (15K); Self-encrypting drives available
Embedded NIC Broadcom® 5720 Dual Port 1Gb LOM
I/O adapter options 1Gb Ethernet: Broadcom 5720 Dual Port 1Gb NIC; Broadcom 5720 Quad Port 1Gb NIC; Intel I350 Dual Port 1Gb stand-up adapter; Intel I350 Quad Port 1Gb stand-up adapter; 10Gb Converged Ethernet: Brocade® BR1020 Dual Port 10Gb CAN; Qlogic® QLE8262 Dual Port 10Gb DA/SFP+; Broadcom 57810S Dual Port 10Gb Base-T CAN; Broadcom 57810S Dual Port 10Gb DA/SFP+ CAN; 10Gb Ethernet: Intel X520 Dual Port 10Gb DA/SFP+ server adapter; Intel X540 Dual Port 10Gb Base-T adapter; FC8/FC4 HBA: Qlogic QLE2460 4Gb Single Port FC HBA; Qlogic QLE2462 4Gb Dual Port FC HBA; Qlogic QLE2560 8Gb Single Port FC HBA; Qlogic QLE2562 8Gb Dual Port FC HBA; Emulex® Lpe-12000-E 8Gb Single Port FC HBA; Emulex Lpe-12002-E 8Gb Dual Port FC HBA; Brocade 815 8Gb Single Port FC HBA; Brocade 825 8Gb Dual Port FC HBA
Power Platinum efficiency, hot-plug, redundant 350W and 550W power supplies; Bronze efficiency, cabled 350W power supply Auto-ranging power supplies
Availability High-efficiency, hot-plug, redundant power supplies; hot-plug hard drives; TPM; dual internal SD support; fan fault tolerance; optional bezel; information tag; ECC memory, interactive LCD screen; ENERGY STAR® compliant
Remote Management Basic management (default), iDRAC7 with Lifecycle Controller, iDRAC7 Express (upgrade option), iDRAC7 Enterprise (upgrade option), 8GB or 16GB vFlash media (upgrade options)
Systems Management IPMI 2.0 compliant; Dell OpenManage™ Essentials and Dell Management Console; Dell OpenManage Power Center; Dell OpenManage Connections:
  • OpenManage Integration Suite for Microsoft® System Center
  • Dell plug-in for Vmware® vCenter™
  • HP Operations Manager, IBM Tivoli® Netcool®, and CA Network and Systems Management
Rack Support ReadyRailsTM II sliding rails for toolless mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm ReadyRails static rails for toolless mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post (Telco) racks
Operating Systems Microsoft® Windows Server® 2012; Microsoft Windows Server 2012 Essentials; Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V® v2); Novell® SUSE® LinuxEnterprise Server; Red Hat® Enterprise Linux® Virtualizations options: Citrix® XenServer®; Vmware® vSphere® ESX™ and ESXi™; Red Hat Enterprise Virtualization®; For more information on the specific versions and additions, visit Dell.com/Ossupport.


Dell PowerEdge R320 Server w/xByte Warranty

Dell PowerEdge R320 Server w/xByte Warranty

  • CPU(s):  1 x Intel E5 Multi Core
  • Memory: 6 DIMM Slots (Max 192GB)
  • RAID: PERC H310, PERC H710 512MB NV
  • HDD:  2.5" or 3.5" Hot Swap SAS, SATA and Near Line SAS
  • RISER:2 PCIe Slots (1 Full Height, 1 Half Height)
  • Power: 350W or 550W Hot Swap Redundant
  • Condition:  Dell Certified Refurbished
  •
  • Starting at $849.00
  • was $1,399.00
  • save $550.00
  • Custom Configuration



xByte holds an unwavering commitment to delivering the highest quality customer service and products. Our diverse stock, including the Dell PowerEdge R320, is ready to be packed and shipped at a moment’s notice, making us one of the few refurbished Dell PowerEdge R320 server suppliers who can ship within 24-hours of order.

Our Dell PowerEdge R320 Warranty

Purchasing a Dell PowerEdge R320 from xByte isn’t much of a gamble, because not only is this a fantastic Dell server, but we also provide a 14-day no questions asked return policy. In addition to this lengthy return period, we are also happy to offer an industry leading warranty, because we stand by the quality of our Dell PowerEdge R320 servers. Learn about our warranty policy by clicking here.

Certifed Technicians

Our technicians have all been trained by Dell to understand the specific details of the Dell PowerEdge R320 server and they are an important part of our unique equation for success. Every employee at xByte understands that our success hinges on providing great customer service and an amazing customer experience, which is why our technicians are happy to assist with any of your setup or troubleshooting needs for your Dell PowerEdge R320 server.

Customer Friendly Purchase Policy

xByte’s business model and environmental stability go hand in hand. We are happy to purchase our customers used, outdated or off-lease IT equipment in order to refurbish it and resell it on the market, like our Dell PowerEdge R320 servers. Thank you from us and the environment for your contribution to the best server recycling possible.

Whether you’re looking for a Dell PowerEdge R320 server or one of our other high quality products, you will not be disappointed. xByte Technologies is ready to help you find the IT equipment that makes the most sense for your unique needs.
